Engineering: diagrams of loading for simple and composite wooden beams. Engraving by J. Davis after R. Tredgold, 1820.

Engineering: loading of wooden beams. Engraving by J. Davis after Tredgold, 1820.

Civil engineering: three types of wooden centring for bridges. Engraving by J. Davis, 1820, after R. Tredgold.

Civil engineering: elevations and sections of bridges. Engraving by J. Davis, 1820, after R. Tredgold.

Building: floor joists, simple and composite wooden beams. Engraving by J. Davis after R. Tredgold, 1820.

Engineering: loading of iron beams. Engraving by J. Davis after R. Tredgold, 1820.

Engineering: a wide-span wooden truss-beam roof. Engraving by J. Davis after R. Tredgold, 1820.

Engineering: details of various wooden domes. Engraving by J. Davis after R. Tredgold, 1820.

Engineering: roofs. Engraving by J. Davis after Tredgold, 1820.
